Key Features

• Visualization of HV battery structure and operation
• Simulation and visualization of electrical power flow
• Charge rate selector
• Port for connection to other LJ Create EV Panel Trainers
• Start/Stop button
• Service Disconnect Switch
• Controls for adjusting HV battery temperatures
• Battery stack and onboard charger circuit simulation
• Terminals for DC and AC circuit measurements
• Manual or automatic fault insertion with 16 fault scenarios

Educational Applications

This trainer supports both theoretical and practical training by helping users understand:

• First responder loop and service disconnect procedures
• De-energising process for HV batteries
• Charging methods and charging circuits
• Charge controller operation
• HV battery stack introduction
• HV battery management systems (BMS)
• HV battery modules and cells
• Module controllers and sensing systems
• HV battery cell balancing
• Temperature monitoring and control

Troubleshooting Training

The trainer includes built-in fault simulation for real-world diagnostics practice, including:

• HV battery troubleshooting
• CAN Bus fault diagnosis
• HV distribution system troubleshooting
• Contactor failure diagnosis
• Intermittent cell issue troubleshooting
• Faulty sensor detection
• Charging system fault troubleshooting

Items Included

• EV Batteries and Charging Panel Trainer
• Digital curriculum materials
• Wall mounting brackets
• Bench stands

Additional Equipment Required

• Lab scope
• Digital multimeter

General Specifications

• Trainer Dimensions: 900 × 170 × 600 mm (W × D × H)
• Packed Volume: Approx. 0.316 m³
• Packed Weight: Approx. 26 kg
• Order Code: 741-01 P9613-I
